Monitor Wall

Monitor Wall

Designed for surveillance centers, Monitor Wall enables operators to view multiple live cameras across up to four high-resolution screens. Its scalable decoding and flexible layouts deliver seamless integration and real-time situational awareness.

  • View multiple live cameras on large screens in your surveillance center

  • Multi-channel decoder with up to four screens

  • Screen layout independently configurable per display

  • Compatible with BVMS

  • Compatible with IP cameras and encoders, as well as ONVIF and RTSP video sources

Product CatalogDownload Datasheet

Product Overview

View multiple live cameras on large screens

Transform your surveillance center with scalable decoding that delivers clear, real-time visibility across up to four high-resolution displays.

Visualize real-time video analytics data

Display onboard analytics metadata as vector overlays to instantly track object detection and classification across your facility.

Customize screen layouts for every display

Adapt automatically to different monitor aspect ratios and orientations to ensure operators see exactly what they need.

Integrate seamlessly with existing video systems

Connect effortlessly with BVMS, IP cameras, and ONVIF video sources without disrupting your current operational workflows.

Maintain smooth video during critical events

Rely on automated performance management to reduce network jitter and deliver stable, low-latency video feeds up to 60 frames per second.

Key Specifications

Key specifications
HardwareManagement workstation Z2 or Z4 (G4 and newer)
Operating systemWindows 11 (64 bit)
Graphic cardNVIDIA Quadro P620 or P4000, NVIDIA RTX 4000, T1000, or A400.
Ethernet card1000 Mbps
Sound cardRecommended
Memory (RAM) (GB)8 GB
Free space (MB)200 MB
Recommended software for configurationConfiguration Manager 7.77 or newer
Recommended software for operationBVMS 12 or newer
EncryptionTLS 1.2; AES
Protocols / standardsIPv4; IPv6; UDP; TCP; HTTP; HTTPS; RTSP; RTP
Frame rate (fps)60 fps
Video compressionH.264 (ISO/IEC 14496-10); H.265/HEVC

Frequently Asked Questions

Common questions about the Monitor Wall

Monitor Wall can render metadata from onboard video analytics engines as a vector graphics overlay directly on the video stream. This enables operators to easily monitor object detection, object tracking, and object classification in real time, turning video into actionable insight.

Yes, the screen layout is independently configurable per display. Depending on the workstation's performance, it can run single, dual, or quad screens with diverse layouts—ranging from full screen to 6x5 views—adapting automatically to monitor aspect ratios and orientations.

Monitor Wall is fully compatible with BVMS to enhance display capabilities in large control centers. It also seamlessly integrates with IP cameras and encoders, as well as ONVIF and RTSP video sources, ensuring simple deployment across diverse IT environments.

The software features scalable decoding technology and a performance management architecture that automatically distributes resources over connected streams. It supports hardware-accelerated H.264 and H.265 decoding, optimizing GPU and CPU load balancing to deliver smooth, high-resolution video up to 60 frames per second.

Yes, the software supports secure access and connection setups, making it easy to integrate into strict IT management environments. It utilizes TLS 1.2 and AES encryption and is designed to run seamlessly on FIPS-2 compliant workstations.
