Fixed dome 2MP HDR 3.2-10.5mm IP66
The FLEXIDOME outdoor 5100i family features built-in IVA Pro analytics, starlight technology, two-way audio, and robust weather resistance for a wide range of outdoor applications.
Commercial Type No: NDE-5702-A
5 MP for highly detailed images
Starlight camera technology with excellent low-light performance
IVA Pro brings highly reliable deep-learning based detection of persons and vehicles to scenes ranging from sterile zones to crowded and congested
High Dynamic Range to see every detail in both bright and dark areas of the scene
Product Overview
Detect what matters with deep learning
Built-in IVA Pro Buildings reliably detects and classifies persons and vehicles while filtering out environmental noise like moving trees or rain.
Capture essential detail even in challenging light
Starlight technology and High Dynamic Range ensure you can clearly identify objects and individuals in both bright sunlight and low light.
Maintain awareness in the toughest weather
Safeguarded against rain, dust, and vandalism, the rugged housing meets IK10 and IP66 for reliable operation across outdoor temperatures.
Simplify deployment to reduce installation time
A simple click and rotate mechanism combined with remote varifocal adjustment makes physical installation and focusing fast and effortless.
Keep critical data safe
Built-in Secure Element hardware and advanced certificate handling ensure your video streams and device access remain completely cyber-resilient.
Key Specifications
| Sensor type | 1/2.8 inch CMOS |
| Resolution | 2 MP |
| Low light technology | starlight |
| WDR technology | HDR |
| Frame rate (fps) | 1 fps – 60 fps |
| Lens focal length (mm) | 3.2 to 10.5 mm |
| Horizontal field of view (°) | 105° – 31° |
| Field of view adjustment | Motorized zoom/focus |
| Video compression | H.264 / AVC; H.265 / HEVC; M-JPEG |
| IP rating | IP66 |
| Impact protection | IK10 ; NEMA 4X |
| Operating temperature | -40 °C – 55 °C (-40 °F – 131 °F) |
| Analytics (built-in) | IVA Pro Buildings ; IVA Pro Privacy |
| Analytics (available) | IVA Pro Perimeter ; IVA Pro Traffic ; IVA Pro Appearance ; IVA Pro Personal Protective Equipment ; IVA Pro Visual Gun Detection ; IVA Pro License Plate ; IVA Pro Vehicle Make Model ; IVA Pro Dangerous Good Signs ; Intelligent Audio Analytics |
Frequently Asked Questions
Common questions about the Fixed dome 2MP HDR 3.2-10.5mm IP66
The camera combines starlight technology and High Dynamic Range (HDR) to deliver highly detailed 1080p video. This multiple-exposure process captures critical details in both bright highlights and dark shadows, ensuring excellent low-light performance and clear visibility in demanding outdoor environments.
The camera comes with IVA Pro Buildings pre-installed, bringing highly reliable, deep neural network-based detection of persons and vehicles. It is extremely resistant to false triggers caused by rain, wind, snow, and shadows, allowing operators to reliably detect and track activity in scenes ranging from sterile zones to crowded areas.
By pairing IVA Pro analytics with optional two-way audio capabilities, the system enriches full situational awareness. Audio detection can generate immediate alarms to alert operators, while the external audio line input and output allow security personnel to communicate directly with visitors or intruders, enabling faster and more confident action.
The modular structure features a click-and-rotate mechanism that requires no hardware to secure the camera to its housing. Combined with Power-over-Ethernet (PoE) and an Automatic Varifocal (AVF) feature, installers can quickly adjust the zoom and focus without opening the camera, significantly reducing installation time and effort.
The system features a built-in Secure Element (SE) providing main Trusted Platform Module (TPM) functionality to ensure the highest levels of data security. Together with Public Key Infrastructure (PKI) support, three-level password protection, and encrypted private keys, the camera delivers superior protection against malicious attacks.
